MASUMA BRAKE DISC
VENDOR CODE: BD-1219
Remark: Diameter of section circle:62.3 Standard thickness:49 Minimum thickness:28 Diameter of section circle:254.5
The manufacturer reserves the right to change the characteristics, appearance, configuration of the goods and the place of its production without notice.
ABOUT THE PRODUCT
APPLICABILITY
OEM
BRAND NUMBER
43512-33020
43512-33050
GAIA
Chassis No. Year Configuration
CXM10G 1998/05-2001/04 2.2L Diesel 3CTE EFI (94 hp / 69 kW) Front wheel drive.
SXM10G 1998/05-2001/04 2.0L Petrol 3SFE EFI (135 hp / 99 kW) Front wheel drive.
SXM15G 1998/05-2001/04 2.0L Petrol 3SFE EFI (135 hp / 99 kW) Four-wheel drive (4WD).
IPSUM
Chassis No. Year Configuration
CXM10G 1997/09-2001/05 2.2L Diesel 3CTE EFI (94 hp / 69 kW) Front wheel drive.
SXM10G 1996/05-2001/05 2.0L Petrol 3SFE EFI (135 hp / 99 kW) Front wheel drive.
SXM15G 1996/05-2001/05 2.0L Petrol 3SFE EFI (135 hp / 99 kW) Four-wheel drive (4WD).
PICNIC
Chassis No. Year Configuration
CXM10L 1997/09-2001/05 2.2L Diesel 3CTE EFI (90 hp / 66 kW) Front wheel drive.
SXM10L 1996/09-2001/05 2.0L Petrol 3SFE EFI (136 hp / 100 kW) Front wheel drive.
SCEPTER
Chassis No. Year Configuration
SXV10 1993/08-1996/08 2.2L Petrol 5SFE EFI (140 hp / 103 kW) Front wheel drive.
SXV10 1992/11-1993/08 2.2L Petrol 5SFE EFI (140 hp / 103 kW) Front wheel drive.
CAMRY
Chassis No. Year Configuration
SXV10L 1992/03-1994/08 2.2L Petrol 5SFE EFI (125 hp / 92 kW) Front wheel drive.
SXV10L 1991/06-1993/08 2.2L Petrol 5SFE EFI (125 hp / 92 kW) Front wheel drive.
SXV10L 1993/09-1994/08 2.2L Petrol 5SFE EFI (125 hp / 92 kW) Front wheel drive.
SXV10L 1993/08-1996/08 2.2L Petrol 5SFE EFI (125 hp / 92 kW) Front wheel drive.
SXV10L 1991/09-1992/03 2.2L Petrol 5SFE EFI (125 hp / 92 kW) Front wheel drive.
SXV10L 1993/08-1994/02 2.2L Petrol 5SFE EFI (125 hp / 92 kW) Front wheel drive.
SXV10L 1992/03-1994/08 2.2L Petrol 5SFE EFI (130 hp / 96 kW) Front wheel drive.
SXV10L 1993/09-1996/08 2.2L Petrol 5SFE EFI (136 hp / 100 kW) Front wheel drive.
SXV10L 1992/03-1993/09 2.2L Petrol 5SFE EFI (136 hp / 100 kW) Front wheel drive.
SXV10L 1991/06-1993/08 2.2L Petrol 5SFE EFI (136 hp / 100 kW) Front wheel drive.
SXV20L 1996/08-1999/08 2.2L Petrol 5SFE EFI (131 hp / 96 kW) Front wheel drive.
SXV20L 1997/08-2000/08 2.2L Petrol 5SFE EFI (133 hp / 98 kW) Front wheel drive.
SXV20L 1996/08-1999/08 2.2L Petrol 5SFE EFI (133 hp / 98 kW) Front wheel drive.
CAMRY GRACIA
Chassis No. Year Configuration
SXV20 1996/12-2001/09 2.2L Petrol 5SFE EFI (140 hp / 103 kW) Front wheel drive.
SXV20W 1996/12-2001/09 2.2L Petrol 5SFE EFI (140 hp / 103 kW) Front wheel drive.
MARK II QUALIS
Chassis No. Year Configuration
SXV20W 1997/04-2001/12 2.2L Petrol 5SFE EFI (140 hp / 103 kW) Front wheel drive.

Masuma brake discs are made from ductile iron with nodular graphite. The high precision of the castings with tolerances of up to several microns guarantees the correct geometry of the disk and the absence of vibrations during operation.

Masuma manufactures two types of brake discs: ventilated and non-ventilated . Almost all models have a non-directional coating of the working surface. This ensures fast and uniform lapping after installation.

Warranty for brake discs 12 months . Wherever you buy or install a part, within a year you have the right to return it, simply by providing him with a receipt or other document confirming the date of purchase and the price. Even if you are not a certified auto mechanic and installed the part yourself in your garage, just keep the purchase receipt and if there is a problem, you can always return the part.

Masuma is a global brand of automotive parts, accessories and consumables. The main specialization of the brand: resource parts for after-sales service of Japanese cars. The company's strategy is to offer consumers the best ratio of reliability and price of spare parts.

MASUMA No. BOSCH No. BOSCH No. BREMBO No. NIBK No. TEXTAR No. TRW No.
BD-1219 0986478726 0986AB9514 09.5623.11 RN1008V 92077603 DF1430
