Full Product Catalog

MASUMA ENGINE GASKET
VENDOR CODE: MD-05013S
Remark: Length:425mm Width:187mm Bore Diameter:87mm
The manufacturer reserves the right to change the characteristics, appearance, configuration of the goods and the place of its production without notice.
ABOUT THE PRODUCT
APPLICABILITY
OEM
BRAND NUMBER
12251-PNA-004
12251-PNC-003
EDIX
Chassis No. Year Configuration
BE3 2004/07-2009/08 DBA-BE3 2.0L Gasoline K20A PGM-FI Front wheel drive.
BE4 2004/07-2009/08 ABA-BE4 2.0L Gasoline K20A PGM-FI Four wheel drive (4WD).
INTEGRA
Chassis No. Year Configuration
DC5 2004/03-2007/02 ABA-DC5 2.0L Gasoline K20A PGM-FI (220 HP / 162 kW) Front wheel drive.
DC5 2001/07-2004/03 LA-DC5 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Front wheel drive.
CR-V
Chassis No. Year Configuration
RD4 2004/03-2004/09 ABA-RD4 2.0L Gasoline K20A PGM-FI Front wheel drive.
RD4 2001/09-2004/03 LA-RD4 2.0L Gasoline K20A PGM-FI Front wheel drive.
RD5 2004/03-2004/09 ABA-RD5 2.0L Gasoline K20A PGM-FI Four wheel drive (4WD).
RD5 2001/09-2004/03 LA-RD5 2.0L Gasoline K20A PGM-FI Four wheel drive (4WD).
STEPWGN
Chassis No. Year Configuration
RF3 2004/02-2005/05 CBA-RF3 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Front wheel drive.
RF3 2001/04-2003/08 LA-RF3 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Front wheel drive.
RF3 2003/06-2004/02 UA-RF3 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Front wheel drive.
RF4 2004/02-2005/05 CBA-RF4 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Four wheel drive (4WD).
RF4 2001/04-2003/08 LA-RF4 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Four wheel drive (4WD).
RF4 2003/06-2004/02 UA-RF4 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Four wheel drive (4WD).
RF5 2004/02-2005/05 CBA-RF5 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Front wheel drive.
RF5 2003/06-2004/02 UA-RF5 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Front wheel drive.
RF6 2004/02-2005/05 CBA-RF6 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Four wheel drive (4WD).
RF6 2003/06-2004/02 UA-RF6 2.0L Gasoline K20A PGM-FI (160 HP / 118 kW) Four wheel drive (4WD).
STREAM
Chassis No. Year Configuration
RN3 2004/01-2006/07 CBA-RN3 2.0L Gasoline K20A PGM-FI (156 HP / 115 kW) Front wheel drive.
RN3 2000/01-2003/09 LA-RN3 2.0L Gasoline K20A PGM-FI (156 hp / 115 kW) Front wheel drive.
RN3 2003/09-2004/01 UA-RN3 2.0L Gasoline K20A PGM-FI (156 HP / 115 kW) Front wheel drive.
RN4 2004/01-2006/07 ABA-RN4 2.0L Gasoline K20A PGM-FI (158 HP / 116 kW) Four wheel drive (4WD).
RN4 2001/01-2004/01 LA-RN4 2.0L Gasoline K20A PGM-FI (156 HP / 115 kW) Four wheel drive (4WD).

In the production of Masuma cylinder head gaskets , intensive test cycles are carried out on test benches to ensure that the sealing requirements of modern engines are met.

Masuma cylinder head gaskets are elastomeric and are available in two versions:

  • Cylinder head gaskets with metal elastomers. Subdivided: into single-layer metal gaskets and multi-layer (2 layers or more).
  • Non-metallic elastomeric cylinder head gaskets with graphite coating (graphite elastomeric cylinder head gasket).

Gaskets are not prone to burn-out - this is real high-tech from Masuma , which just a few years ago, auto mechanics could not even dream of.

Warranty for cylinder head gaskets 12 months. Wherever you buy or install a part, within a year you have the right to return it, simply by providing him with a receipt or other document confirming the date of purchase and the price. Even if you are not a certified auto mechanic and installed the part yourself in your garage, just keep the purchase receipt and if there is a problem, you can always return the part.

Masuma is a global brand of automotive parts, accessories and consumables. The main specialization of the brand: resource parts for after-sales service of Japanese cars. The company's strategy is to offer consumers the best ratio of reliability and price of spare parts. All products are manufactured to order, technologies and under the control of the parent company Masuma Auto Spare Parts Co., LTD (Tokyo, Japan) at dozens of modern factories located in East Asia.

MASUMA No.
MD-05013S
