MASUMA TIE ROD END
VENDOR CODE: ME-2953R
Remark: External Thread x Female Thread:14x1.5mm Taper Diameter:16mm External Thread x Female Thread:21x1.5mm Center Distance:143.4mm
The manufacturer reserves the right to change the characteristics, appearance, configuration of the goods and the place of its production without notice.
ABOUT THE PRODUCT
APPLICABILITY
OEM
BRAND NUMBER
45045-69065
LX450
Chassis No. Year Configuration
FZJ80L 1995/11-1998/01 4.5L Petrol 1FZFE EFI (205 hp / 151 kW) Four-wheel drive (4WD).
LAND CRUISER
Chassis No. Year Configuration
FZJ80G 1992/08-1998/01 4.5L Petrol 1FZFE EFI (215 hp / 158 kW) Four-wheel drive (4WD).
FZJ80L 1992/08-1998/01 4.5L Petrol 1FZFE EFI (205 hp / 151 kW) Four-wheel drive (4WD).
FZJ80L 1992/08-1998/01 4.5L Petrol 1FZFE EFI (212 hp / 156 kW) Four-wheel drive (4WD).
FZJ80L 1992/08-1998/01 4.5L Petrol 1FZFE EFI (292 hp / 215 kW) Four-wheel drive (4WD).
HDJ80L 1995/01-1998/01 4.2L Diesel 1HDFT (170 hp / 125 kW) Four-wheel drive (4WD).
HDJ80L 1990/01-1995/01 4.2L Diesel 1HDT (167 hp / 123 kW) Four-wheel drive (4WD).
HDJ81V 1995/01-1998/01 4.2L Diesel 1HDFT (170 hp / 125 kW) Four-wheel drive (4WD).
HDJ81V 1990/01-1995/01 4.2L Diesel 1HDT (165 hp / 121 kW) Four-wheel drive (4WD).
HZJ80L 1990/01-1998/01 4.2L Diesel 1HZ (135 hp / 99 kW) Four-wheel drive (4WD).
HZJ81V 1990/01-1998/01 4.2L Diesel 1HZ (135 hp / 99 kW) Four-wheel drive (4WD).
KZJ70L 1993/05-1996/04 3.0L Diesel 1KZT (125 hp / 92 kW) Four-wheel drive (4WD).
KZJ70LV 1993/05-1996/04 3.0L Diesel 1KZT (125 hp / 92 kW) Four-wheel drive (4WD).
KZJ73LV 1993/05-1996/04 3.0L Diesel 1KZT (125 hp / 92 kW) Four-wheel drive (4WD).
KZJ77LV 1993/05-1996/04 3.0L Diesel 1KZT (125 hp / 92 kW) Four-wheel drive (4WD).
KZJ77RV 1993/05-1996/04 3.0L Diesel 1KZT (125 hp / 92 kW) Four-wheel drive (4WD).
LJ70L 1990/01-1993/05 2.4L Diesel 2LT (96 hp / 71 kW) Four-wheel drive (4WD).
LJ70LV 1990/01-1995/01 2.4L Diesel 2LT (96 hp / 71 kW) Four-wheel drive (4WD).
LJ72L 1990/04-1993/05 2.8L Diesel 3L (91 hp / 67 kW) Four-wheel drive (4WD).
LJ72LV 1990/04-1996/04 2.8L Diesel 3L (91 hp / 67 kW) Four-wheel drive (4WD).
LJ72RV 1990/04-1996/04 2.8L Diesel 3L (91 hp / 67 kW) Four-wheel drive (4WD).
LJ73LV 1990/01-1994/08 2.4L Diesel 2LT (96 hp / 71 kW) Four-wheel drive (4WD).
LJ77LV 1990/04-1993/05 2.4L Diesel 2LT (96 hp / 71 kW) Four-wheel drive (4WD).
LJ77RV 1990/04-1993/05 2.4L Diesel 2LT (96 hp / 71 kW) Four-wheel drive (4WD).
LJ79LV 1990/04-1996/04 2.8L Diesel 3L (91 hp / 67 kW) Four-wheel drive (4WD).
LJ79RV 1990/04-1996/04 2.8L Diesel 3L (91 hp / 67 kW) Four-wheel drive (4WD).
RJ70L 1990/01-1994/01 2.4L Petrol 22R Carburetor (108 hp / 79 kW) Four wheel drive (4WD).
RJ70LV 1990/01-1996/04 2.4L Petrol 22R Carburetor (108 hp / 79 kW) Four wheel drive (4WD).
RJ70LV 1990/01-1993/05 2.4L Petrol 22R Carburetor (108 hp / 79 kW) Four wheel drive (4WD).
RJ70LV 1990/01-1996/04 2.4L Petrol 22RE EFI (109 hp / 80 kW) Four-wheel drive (4WD).
RJ73LV 1990/01-1996/04 2.4L Petrol 22RE EFI (109 hp / 80 kW) Four-wheel drive (4WD).
RJ77LV 1990/04-1996/04 2.4L Petrol 22R Carburetor (108 hp / 79 kW) Four wheel drive (4WD).
RJ77RV 1990/04-1996/04 2.4L Petrol 22R Carburetor (108 hp / 79 kW) Four wheel drive (4WD).
LAND CRUISER PRADO
Chassis No. Year Configuration
KZJ71G 1993/05-1996/04 3.0L Diesel 1KZTE (130 hp / 96 kW) Four-wheel drive (4WD).
KZJ71W 1993/05-1996/04 3.0L Diesel 1KZTE (130 hp / 96 kW) Four-wheel drive (4WD).
KZJ78G 1993/05-1996/04 3.0L Diesel 1KZTE (130 hp / 96 kW) Four-wheel drive (4WD).
KZJ78W 1993/05-1996/04 3.0L Diesel 1KZTE (130 hp / 96 kW) Four-wheel drive (4WD).
LJ71G 1990/04-1993/05 2.4L Diesel 2LTE EFI (97 hp / 71 kW) Four-wheel drive (4WD).
LJ78G 1990/04-1993/05 2.4L Diesel 2LTE EFI (97 hp / 71 kW) Four-wheel drive (4WD).
LJ78W 1991/08-1993/05 2.4L Diesel 2LTE EFI (97 hp / 71 kW) Four-wheel drive (4WD).

Masuma tie rod ends are manufactured using state-of-the-art non-separable technology. The details of the ball bearings of the tips are made of Cr40 alloy steel with hardening . The mirror processing technology ensures that the surface roughness of the ball pin is no more than 0.4 microns, which significantly increases the service life of the hinge. The design and processing technology of the ball joint ensure that even with large angular loads, the ball joint will not jump out of its regular seat.

Guarantee for steering tips 12 months . Wherever you buy or install a part, within a year you have the right to return it, simply by providing him with a receipt or other document confirming the date of purchase and the price. Even if you are not a certified auto mechanic and installed the part yourself in your garage, just keep the purchase receipt and if there is a problem, you can always return the part.

Masuma is a global brand of automotive parts, accessories and consumables. The main specialization of the brand: resource parts for after-sales service of Japanese cars. The company's strategy is to offer consumers the best ratio of reliability and price of spare parts.

MASUMA No. 555 No. CTR No. TRW No.
ME-2953R SE2953R CET-77 JTE903
